This database is for vintage and classic Epco vehicle jacks.  Many of the photos and comments have been gleaned from Ebay and other sites.  I would be pleased to add photos and comments from anyone who has information on these jacks.

Please note that this information is accurate to the best of my knowledge, but I make no claims about authority on this subject. Use your own discretion when evaluating the accuracy of the information.

Many Epco jacks are now very old.  I would recommend that they are now used only for display purposes.  If one is used for lifting a vehicle, the operator should never put them self underneath the supported area without additional load bearing equipment in place, such as block of wood. Never use bricks for this purpose.

New seals are available for these jacks. Please see the link on the home page.

The values are normally taken from auction sites world-wide, but exclude postage.

Request to vendors: Please feel free to use the information from these databases in your adverts. An acknowledgement of the source would be most welcome. However, please do not twist any of the information. Where I say along the lines: 'May be for car X' please make this clear in your advert. An altered statement saying: 'It is for car X' will create false facts and misinformation. If you know for certainty a jack's heritage please contact me so that I can amend the entry. Thank you.



General Notes on Epco Jacks

Epco used numbering across all the range 55 /60 /65/70/75/etc.

A/B/C/K/V/T were the prefix letters.

A/B/C were all the same frame with the difference being the seal packing kit.

Early models had glands that tightened up on a leather and fabric seal. This was followed by rubber fabric.

In the C series they moved over to an O ring with a scraper or wiper ring held in by a circlip. The main ram seal remained the same with a cup seal made of a composite material.

The V series had a number of problems; the alloy block was very weak and the pump plunger used to break through the bottom of the block. The ball bearing valves were prone to braking through the valve seat and the main ram was sealed only by O rings with a ptfe backup split ring.

The T series replaced the V series and resolved these problems. The visible difference was the maximum height bar connected to the release / overload valve.

Brockhouse Harvey Frost bought out Epco keeping the T series alive. They stopped producing spares for the A/B/C series but had to reintroduce them for the C series as the UK MOD had so many of these jacks.

Attached is a page from a George Hatch brochure listing a number of Epco trolley jacks with their specifications. Kindly sent to me by PJ O-Furey: Epco Hydraulic Trolley Jacks .

Attached also are the Operating and Service Instructions For Epco Trolley Jacks kindly sent to me by Geoff Ed.



 Trolley Jacks followed by Tower Jacks and Axle Load Check Unit




















Epco 1.5 Tons

Description:

The Epco 1 1/2 tons trolley jack is most likely pre war. It has 2 brass plaques. The first reads: EPCO LTD, STAR WORKS, SKINNER LANE, LEEDS, ENGLAND, MODERN GARAGE EQUIPMENT, No. 0302. The other reads: CAPACITY 1 1/2 TONS.

The lift is 19”; the handle is 43” tall; overall length is 38”; max width is 15.5”; the wheel track is 12”, same front and rear.

Photos and data courtesy of Tim Lyon.

Applicable Vehicles:

Garage trolley jack.

Jack Handle Type:

Fixed.

Year Dates Noted:

Probably pre war.

Value:

£20.00 paid on UK Ebay 21 January 2024







Epco 2 Ton

Description:

Only details as shown in the photo.

Applicable Vehicles:

Garage trolley jack.

Jack Handle Type:

Fixed.

Year Dates Noted:



Value:

Average price paid in 2015 = £36.00 - 1 sale









Epco BJ5

Description:

The BJ5 is an unusual upright axle/bumper jack. The casting on top of the pedestal reads EPCO BJ5 CAPACITY 3000 LBS EPCO LTD LEEDS ENGLAND. Adjacent is a lever with 2 cast arrows labelled UP and DOWN. It measures 38" tall, 39" wide and the base 24" x 24".

Applicable Vehicles:

Garage axle/bumper jack.

Jack Handle Type:

Fixed.

Year Dates Noted:



Value:











Epco 5 Ton

Description:

 52" long. 24" lift Top plate cast 5 TON EPCO. Only other details as shown in the photos - Courtesy of David Bosley.

Applicable Vehicles:

Garage trolley jack.

Jack Handle Type:

Fixed.

Year Dates Noted:



Value:

Average price paid in 2018 = £25.00 - 1 sale

Average price paid in 2020 = £65.00 -  2 sales

Average price paid in 2021 = £12.50 - 1 sale









Epco De Luxe No.5

Description:

The jack is cast EPCO DE LUXE No.5 30 CWT. Photos courtesy James Watson.

Applicable Vehicles:

Garage trolley jack.

Jack Handle Type:

Integrated.

Year Dates Noted:



Value:

Average price paid in 2017 = £36.00 - 1 sale









Epco Deluxe No.10

Description:

The Epco Deluxe No.10 trolley jack has a 2.5 ton lift. The main casting detail is EPCO DELUXE No.10. Other detail as in the photos.

Applicable Vehicles:

Garage trolley jack.

Jack Handle Type:

integrated.

Year Dates Noted:



Value:

Average price paid in 2022 = £36.00 - 1 sale









Epco Deluxe 2.5 Ton

Description:

The jack is cast EPCO DELUXE IMPORTANT FILL WITH CLEAN LIGHT GRADE OIL ONLY CAPACITY 2 1/2 TONS. Only other details as shown in the photos

Applicable Vehicles:

Garage trolley jack.

Jack Handle Type:

Integrated.

Year Dates Noted:



Value:

Average price paid in 2017 = £56.00 - 1 sale









Epco No. 10

Description:

The jack is cast EPCO No.10. It has a 2.5 Ton lifting capacity and has a maximum lift to 19.5".  Only other details as shown in the photos.

Applicable Vehicles:

Garage trolley jack.

Jack Handle Type:

Integrated.

Year Dates Noted:



Value:

Average price paid in 2017 = £52.00 - 1 sale

Average price paid in 2021 = £25.00 - 1 sale











Epco Minor 15

Description:

The Epco Minor 15 trolley jack has a 15cwt lift. The casting and label says EPCO LTD, MINOR CAP 15 CWT EPCO LTD LEEDS ENGLAND.

Applicable Vehicles:

Garage trolley jack.

Jack Handle Type:

As shown in 3rd photo.

Year Dates Noted:



Value:

Average price paid in 2015 = £39.74 - 2 sales

Average price paid in 2017 = £39.66 - 3 sales

Average price paid in 2019 = £24.33 - 3 sales

Average price paid in 2020 = £50.00 -  1 sale

Average price paid in 2022 = £24.50 - 2 sales

Average price paid in 2023 = £47.50 - 2 sales

£30.00 paid on UK Ebay 11 October 2024









Epco Hi Lift

Description:

The Epco Hi Lift has a 2.5 ton lifting capacity. Lift height 36 inches.

Applicable Vehicles:

Garage trolley jack.

Jack Handle Type:

Fixed.

Year Dates Noted:



Value:

Average price paid in 2017 = £175.00 - 1 sale

Average price paid in 2023 = £51.00 - 1 sale











Epco No.30

Description:

5 Ton trolley jack. Only other details as shown in the photos.

Applicable Vehicles:

Garage trolley jack.

Jack Handle Type:

Fixed.

Year Dates Noted:



Value:

Average price paid in 2018 = £20.00 - 1 sale









Epco No. 35 Hy Lift

Description:

2.5 Ton trolley jack. Only other details as shown in the photos.

Applicable Vehicles:

Garage trolley jack.

Jack Handle Type:

Fixed.

Year Dates Noted:



Value:

Average price paid in 2016 = £103.33 - 1 sale

Average price paid in 2017 = £72.00 - 1 sale









Epco K40

Description:

The K40 has a 2 Tonne capacity. Only other details as shown in the photos.

Operating Instructions and Spare Parts for K30 & K40.

Applicable Vehicles:

Garage trolley jack.

Jack Handle Type:

Fixed.

Year Dates Noted:



Value:

Average price paid in 2020 = £68.77 -  1 sale

Average price paid in 2021 = £70.00 - 1 sale

£65.00 paid on UK Ebay 22 January 2024









Epco 50

Description:

Only details as shown in the photos.

Applicable Vehicles:

Garage trolley jack.

Jack Handle Type:

Fixed.

Year Dates Noted:



Value:

Average price paid in 2020 = £46.00 -  1 sale

Average price paid in 2023 = £50.00 - 1 sale













Epco Model No. 55

Description:

The Epco 55 trolley jack has a 1.25 ton lift. Only details as shown in the photos.

Applicable Vehicles:

Garage trolley jack.

Jack Handle Type:

Fixed.

Year Dates Noted:



Value:

Average price paid in 2015 = £74.51 - 1 sale

Average price paid in 2017 = £33.00 - 1 sale









Epco Model No. 60

Description:

The Epco 60 trolley jack has a 9000 lb lift. Details as shown in the photos.

Applicable Vehicles:

Garage trolley jack.

Jack Handle Type:

Fixed.

Year Dates Noted:



Value:

Average price paid in 2017 = £31.00 - 1 sale

Average price paid in 2019 = £43.00 - 1 sale

Average price paid in 2023 = £44.99 - 1 sale

£39.99 paid on UK Ebay 28 May 2024











Epco Model No. 65

Description:

The Epco 65 trolley jack has a 2 ton lift. It is stamped No. 65 SERIAL No. xxx MARK III CAPACITY 2032 KGS 4480 LBS EPCO LTD ENGLAND.

The final photo shows 2 hydraulic plugs. Inside the left one as viewed are 2 ball bearings of differing sizes. The first one to be placed in is the smaller of the 2. ie. the larger ball bearing is next to the plug. I mention this as I have received a number of communications from owners who, during jack servicing, have undone the plug then inverting the jack. The ball bearings then scatter to the far corners of the garage! If one or both get lost the lower ball is 3/16" diameter and the upper 3/8".

Applicable Vehicles:

Garage trolley jack.

Jack Handle Type:

Fixed.

Year Dates Noted:

1970, 1975

Value:

Average price paid in 2015 = £50.75 - 5 sales

Average price paid in 2018 = £31.00 - 1 sale

Average price paid in 2019 = £9.60 - 1 sale

Average price paid in 2020 = £21.00 -  1 sale

Average price paid in 2021 = £48.00 -  2 sales

Average price paid in 2022 = £35.00 - 2 sales

Average price paid in 2023 = £34.09 - 4 sales

£36.00 paid on UK Ebay 14 April 2024

£16.05 paid on UK Ebay 27 August 2024







Epco Atom No. 65

Description:

The Epco Atom 65 trolley jack has a 3.5 tonne lift. It is stamped ATOM No. 65. The jack in the photos is missing the rounded cover plate at the base of the handle. Photos courtesy of Karl Burt.

Peter Wilson informs me that the curved plate is labelled 1587kg 3500lbs.

Applicable Vehicles:

Garage trolley jack.

Jack Handle Type:

Fixed.

Year Dates Noted:



Value:

Average price paid in 2015 = £15.00 - 1 sale

Average price paid in 2021 = £26.00 - 1 sale

Average price paid in 2023 = £14.16 - 1 sale













Epco No. 70 (Verilo)

Description:

The Epco 70 trolley jack has a 2.5 ton lift. It is cast EPCO No. 70 2 1/2 TONS TROLLEY JACK.

Min Height 4.5"; Max Height 24"; Highest point of Chassis 6.25"; Width 16"; Chassis length 49"; Length with handle 91".

See here for Epco 70 series exploded diagram.

Applicable Vehicles:

Garage trolley jack.

Jack Handle Type:

Fixed.

Year Dates Noted:



Value:

Average price paid in 2017 = £43.00 - 2 sales

Average price paid in 2020 = £55.99 -  2 sales

Average price paid in 2022 = £50.00 - 1 sale

Average price paid in 2023 = £39.33 - 3 sales

£62.00 paid on UK Ebay 30 September 2024

£18.00 paid on UK Ebay 8 November 2024











Epco Model No. 75 (High Lift)

Description:

The Epco 75 trolley jack has a 2.5 ton lift. It is cast EPCO JACK MODEL No. 75 2 1/2 TONS.

Min Height 5.25"; Max Height 36"; Highest point of Chassis 7.25"; Width 19.5"; Chassis length 63"; Length with handle 105".

See here for Epco 70 series exploded diagram.

Applicable Vehicles:

Garage trolley jack.

Jack Handle Type:

Fixed.

Year Dates Noted:



Value:

Average price paid in 2014 = £52.55 - 1 sale

Average price paid in 2015 = £30.47 - 4 sales

Average price paid in 2016 = £41.00 - 2 sales

Average price paid in 2018 = £84.75 - 2 sales

Average price paid in 2020 = £58.990 -  3 sales

Average price paid in 2021 = £27.00 -  3 sales

Average price paid in 2022 = £118.00 - 2 sales









Epco T75

Description:

The T75 is a 2.5 ton high lift jack. Unfortunately the data plate is missing. It has a lifting height of 36", 70" long and 18" wide. Other details as shown in the photos courtesy of Kim Worrall.

Applicable Vehicles:

Garage trolley jack.

Jack Handle Type:

Fixed.

Year Dates Noted:



Value:

Average price paid in 2017 = £50.00 - 1 sale

Average price paid in 2022 = £52.45 - 1 sale











Epco T75 - Variation 1

Description:

This 5 ton jack has a number of similarities to the one above. Main differences are the shorter reach jack arm; and the lever arrangement behind the handle shaft. Unfortunately the label is damaged where the model number should be displayed.

Interesting to note that the label states "A DIVISION OF FKI BRADBURY.....".

Total Length 147cm; Main Body Length 126cm; Body Width 16.5cm; Body Height 18cm; Max Width inc Wheels 43cm; Lift Arm Length 54cm; Lifting Max Height 60cm; Hand Lever Length 118cm.

Applicable Vehicles:

Garage trolley jack.

Jack Handle Type:

Integrated.

Year Dates Noted:



Value:

Average price paid in 2023 = £150.00 - 1 sale











Epco No. 80 (Standard)

Description:

The Epco 80 trolley jack has a 5 ton lift. It is cast EPCO N0. 80 5 TONS TROLLEY JACK.

Min Height 5"; Max Height 24"; Highest point of Chassis 6.25"; Width 17"; Chassis length 52.25"; Length with handle 90".

Applicable Vehicles:

Garage trolley jack.

Jack Handle Type:

Fixed.

Year Dates Noted:



Value:

Average price paid in 2016 = £60.00 - 1 sale

Average price paid in 2021 = £20.00 - 1 sale

Average price paid in 2023 = £85.00 - 1 sale













Epco No. 85 (High Lift)

Description:

The Epco 85 trolley jack has a 5 ton lift. It is cast EPCO N0. 85 5 TONS 5050 KILOS TROLLEY JACK.

Min Height 6"; Max Height 36"; Highest point of Chassis 10"; Width 20"; Chassis length 66"; Length with handle 108".

Applicable Vehicles:

Garage trolley jack.

Jack Handle Type:

Fixed.

Year Dates Noted:



Value:

Average price paid in 2015 = £103.00 - 1 sale

Average price paid in 2021 = £66.00 - 1 sale











Epco No. 90 (Standard)

Description:

The Epco 90 trolley jack has a 7.5 ton lift. It is cast EPCO JACK MODEL N0. 90 7 1/2 TONS.

Min Height 6"; Max Height 24"; Highest point of Chassis 10"; Width 19"; Chassis length 52.5"; Length with handle 94.5".

Applicable Vehicles:

Garage trolley jack.

Jack Handle Type:

Fixed.

Year Dates Noted:



Value:

Average price paid in 2017 = £32.00 - 1 sale



Similar to the Epco 90 - photo required



Epco No 95 (High Lift)

Description:

The Epco 95 trolley jack has a 7.5 ton lift. It is cast EPCO JACK MODEL N0. 95 7 1/2 TONS.

Min Height 6"; Max Height 36"; Highest point of Chassis 12.5"; Width 21"; Chassis length 67.5"; Length with handle 109.5".

Applicable Vehicles:

Garage trolley jack.

Jack Handle Type:

Fixed.

Year Dates Noted:



Value:









Epco No 100 (Heavy Standard)

Description:

The Epco 100 trolley jack has a 10 Ton lift. It is cast EPCO No.100 10 TONS TROLLEY JACK.

Min Height 6"; Max Height 24"; Highest point of Chassis 10.75"; Width 19.5"; Chassis length 57.5"; Length with handle 99.5".

Applicable Vehicles:

Garage trolley jack.

Jack Handle Type:

Fixed.

Year Dates Noted:



Value:

Average price paid in 2015 = £50.00 - 2 sales

Average price paid in 2019 = £92.00 - 1 sale

Average price paid in 2022 = £55.00 - 1 sale











Epco No 200

Description:

The Epco No. 200 trolley jack has a 20320 Kg capacity. Only other details as shown in the photos which are courtesy of Goran Theander.

Applicable Vehicles:

Garage trolley jack.

Jack Handle Type:

Fixed.

Year Dates Noted:



Value:











Epco Lifting Frame

Description:

Only details of the Epco Lifting Frame as shown in the pictures. Photo copyright Paul Dyson.

Applicable Vehicles:

Garage lifting frame.

Jack Handle Type:

Fixed.

Year Dates Noted:



Value:






Tower Jacks
















Epco Tower Jack

Description

Epco 4 Ton 6.5" triple screw Tower jack. It is cast EPCO 4 TON 6 1/2 INCH TOWER JACK PATS 197859 872871. On the other side it is cast It is cast ERN LAKE 4 TON 6 1/2 INCH TOWER JACK PATS 197859 872871, below which is HARVEY FROST & CO LTD BISHOP'S STORTFORD.

This illustrates the collaboration between companies, both during WW2 and after. This particular example is date stamped 1992.

See also the Harvey Frost and Ern Lake Tower Jack versions.

Applicable Vehicles:

Bedford MK and MJ military vehicles

Jack Handle Type:

As shown in the 5th photo.

Year Dates Noted:

1992

Value:

Average price paid in 2021 = £26.00 - 1 sale




Axle Load Check Unit













Epco Chekaload

Description:

Load unit replaces normal lifting pad on trolley jack. Other details as shown and explained in the photos.

Applicable Vehicles:

Any vehicle.

Jack Handle Type:

Not applicable.

Year Dates Noted:



Value:





Home
