Page 1    Page 2    Page 3    Page 4

Request to vendors: Please feel free to use the information from these databases in your adverts. An acknowledgement of the source would be most welcome. However, please do not twist any of the information. Where I say along the lines: 'May be for car X' please make this clear in your advert. An altered statement saying: 'It is for car X' will create false facts and misinformation. If you know for certainty a jack's heritage please contact me so that I can amend the entry. Thank you.

Page 1: Uncategorised old jacks, Midas screw jacks, then sequential numbered screw jacks

Page 2: Continuation of sequentially numbered screw jacks

Page 3: Hydraulic jacks and Millennium MO series hydraulic jacks.

Page 4: Millex & Millennium M series hydraulic jacks, followed by Trolley jacks.

I am frequently contacted by L&E hydraulic jack owners how to lower their jack.  Commonly, they find the jack in the back of their garage and the first thing they do is pump it up without weight on it to see if it still works.  The answer is to push the handle fully down through a restriction. This operates a pressure release piston. At the same time push down on the central lifting ram.  In normal operation the weight of the car would apply this downward pressure.

See home page for the supplier of L&E jack seals.



Hydraulic Jacks followed by Millennium MO series







Lake & Elliot A5-212

Description

The jack is engraved A5-212 D 93/2 5000KG 27730.4  It is 8.5" closed. It appears to be a single hydraulic cylinder with a manual screw extension. No other details known.

Applicable Vehicles:

not known

Jack Handle Type:

Integrated

Year Dates Noted:

February 1993 (D 92/2)

Value:













Lake & Elliot S133

Description

The S133 is a 4 ton jack with a double hydraulic piston and manual screw extension. It is 6.75" closed; 6.75" lift; 1.5" screw extension; giving an extended height of 15."

Applicable Vehicles:

Not known

Jack Handle Type:

36" long.

Year Dates Noted:



Value:

Average price paid in 2014 = 14.16 - 3 sales

5.95 paid on UK Ebay 28 August 2016 - no handle









Lake & Elliot S142

Description

The S142 is a 6 ton jack with a single piston and manual screw extension. Height closed 9 5/8"; lift 6.5"; screw extension 5 3/8"; giving an extended height of 21.5" It is cast MILLENNIUM on the lever and MADE IN ENGLAND on the body. On the other side it is cast LAKE & ELLIOT LTD 6 TON S142.

Applicable Vehicles:

Not Known

Jack Handle Type:

36" long.

Year Dates Noted:



Value:

Average price paid in 2013 = 4.77 - 3 sales

Average price paid in 2014 = 11.49 - 2 sales

6.00 paid on UK Ebay 29 March 2015

0.01 paid on UK Ebay 18 May 2015

16.00 paid on UK Ebay 9 October 2015 - no handle

10.00 paid on UK Ebay 14 February 2017 - with handle









Lake & Elliot S142 Modified

Description

This S142 differs slightly from the one above. The handle lever is cast P11xx instead of MILLENNIUM and it has a shouldered lifting pin instead of a ring. The other casting detail is also different. This one states S142 LAKE & ELLIOT LTD BRAINTREE 6 TON. Above the lever is 9 1/2. As above it is a 6 ton jack with a single piston and manual screw extension. Height closed 9 5/8"; lift 6.5"; screw extension 5 3/8"; giving an extended height of 21.5" Photos and details courtesy of John Hawking in Australia.

Applicable Vehicles:

Not Known

Jack Handle Type:

36" long.

Year Dates Noted:



Value:











Lake & Elliot S143

Description

The S143 is a 12 ton jack with a single hydraulic piston and manual screw extension. It is 12.5" closed; 7 7/8" lift; 6.5" screw extension; giving an extended height of 26 7/8". Cast with S143. Millennium C V Hydro. 12 Ton.

Applicable Vehicles:

Not Known

Jack Handle Type:

36" long

Year Dates Noted:



Value:

21.11 paid on UK Ebay 5 May 2013









Lake & Elliot H277

Description

Cast with LAKE & ELLIOT LTD BRAINTREE on one side and H277 on the other. No other details known.

Applicable Vehicles:

Not known

Jack Handle Type:

Not known

Year Dates Noted:



Value:











Lake & Elliot H281A

Description

Cast with H281A LAKE & ELLIOT LTD BRAINTREE 7 TON. No other details known.

Applicable Vehicles:

Not known

Jack Handle Type:

Not known

Year Dates Noted:



Value:

20.00 paid on UK Ebay 24 October 2015

10.00 paid on UK Ebay 6 October 2016 - WH











Lake & Elliot S343A

Description

The S343A is a 6 ton jack with a single hydraulic piston and manual screw extension. It is 9.25" closed; 6 1/8" lift; 4.25" screw extension; and extended height of 19 5/8". Cast on one side 6 TON HYDRO PATENT Nos 322567 359761 and on the other LAKE & ELLIOT LTD BRAINTREE ENGLAND S343A 9 1/4 INCHES. It looks like the same casting as the MILLENNIUM M6 DP. Photos courtesy of Brod Hart.

Applicable Vehicles:

Not Known

Jack Handle Type:

36" long.

Year Dates Noted:



Value:











Lake & Elliot 354

Description

The jack is a 2 Ton. No other details known.

Applicable Vehicles:

Not Known

Jack Handle Type:

Not Known

Year Dates Noted:



Value:

4.00 paid on UK Ebay 5 January 2014









Lake & Elliot S356 B

Description

The S356 is a 4 Ton jack with a single hydraulic piston and manual screw extension. It is cast LAKE & ELLIOT LTD 4 TON S356 B. Height closed 9.25"; lift 6.5"; 5 3/8" screw extension; and extended height of 21 1/8".

Applicable Vehicles:

Not Known

Jack Handle Type:

36" long.

Year Dates Noted:



Value:

Average price paid in 2013 = 2.99 - 2 sales

8.50 paid on UK Ebay 30 April 2014

25.00 paid on UK Ebay 11 October 2014

8.00 paid on UK Ebay 16 October 2014









Lake & Elliot Midas S388

Description

The S388 is a 6 Ton jack with a double hydraulic piston and manual screw extension.  Height closed 8 1/8"; lift 8.75"; screw extension 2.5"; giving an extended height of 19 3/8".

Applicable Vehicles:

Not known

Jack Handle Type:

36" long.

Year Dates Noted:



Value:

1.11 paid on UK Ebay 6 January 2013

10.00 paid on UK Ebay 9 March 2014

8.00 paid on UK Ebay 5 March 2017 - WH









Lake & Elliot S391

Description

The S391 is an 8 Ton jack with a double hydraulic piston and manual screw extension.  It is cast S391 LAKE & ELLIOT BRAINTREE ENGLAND 10 1/4 IN on one side and MILLENNIUM HYDRO 8 TON on the other. Height closed 10.25". Photos and information courtesy of NewMoody.

Applicable Vehicles:

Not known

Jack Handle Type:

36" long, as shown in 4th photo. I believe the rivet in the handle is designed to hit the cast stop when raising. To lower I presume the handle is rotated and the socket is then pushed down past the cast stop.

Year Dates Noted:



Value:











Lake & Elliot S473

Description

The S473 is a 6 Ton jack It is double lift hydraulic with a manual screw extension. Height closed 8.75", double lift 10 3/8", screw lift 3", giving an extended height of 22 1/8". It is cast LAKE & ELLIOT LTD BRAINTREE ENGLAND S473 6 TONS.

Applicable Vehicles:

Not known.

Jack Handle Type:

36" long as shown in final 2 photos.

Year Dates Noted:



Value:

7.00 paid on UK Ebay 21 December 2013

8.50 paid on UK Ebay 14 August 2016 - with handle









Lake & Elliot S640

Description

The S640 is an 8 ton jack with a single piston and manual screw extension. Height closed 10 1/8"; lift 7"; screw extension 5 1/8"; giving an extended height of 22.25"

Applicable Vehicles:

Not Known

Jack Handle Type:

36" long.

Year Dates Noted:



Value:











Lake & Elliot S646

Description

The S646 is a 1 ton jack. It is a single hydraulic piston and a manual screw extension. The hydraulic raising appears to be by a rotating lug. Cast with LAKE & ELLIOT LTD BRAINTREE on one side and 1 TON S646 + patent numbers as shown in the photos. Height closed is 7"; lift 4.75"; screw extension 3 7/8"; extended height 15 5/8".

Applicable Vehicles:

Not Known

Jack Handle Type:

As shown in photos. Interesting riveted plate on handle giving operating instructions. length 30".

Year Dates Noted:



Value:

19.19 paid on UK Ebay 17 July 2013

10.00 paid on UK Ebay 22 February 2014

25.49 paid on UK Ebay 02 August 2014

32.99 paid on UK Ebay 2 July 2016 - WH









Lake & Elliot S723



Description

The Millennium S723 is a 1 ton jack with a double hydraulic piston and manual screw extension. It is 5" closed; 6 1/8" lift; 2" screw extension; giving an extended height of 13 1/8".

Applicable Vehicles:

Aston Martin DB2.  I have the M1DL (very similar specification) listed for the DB2/4.

Jack Handle Type:

30" long with brass plate on shaft cast with raising and lowering instructions (final two photos).

Year Dates Noted:



Value:

Average price paid in 2014 = 161.07 - 5 sales

Average price paid in 2015 = 182.90 - 7 sales

99.99 paid on UK Ebay 18 July 2016 - no handle

40.00 paid on UK Ebay 10 September 2016 - no handle

183.00 paid on UK Ebay 2 November 2016 - no handle

37.00 paid on UK Ebay 22 July 2017 - WH

60.00 paid on UK Ebay 27 July 2017 - WH

65.00 paid on UK Ebay 13 August 2017 - WH









Lake & Elliot S794

Description

The Millennium S794 is a 20 ton jack with a single hydraulic piston and manual screw extension. It is 10.5" closed; 6.25" lift; 4.25" screw extension; giving an extended height of 21"

This jack looks identical to the M20 shown on the final page.

Applicable Vehicles:

Not known

Jack Handle Type:

36" long.

Year Dates Noted:



Value:

5.00 paid on UK Ebay 24 February 2016 - with handle









Lake & Elliot S829

Description

The Millennium S829 is a 10 ton jack with a single hydraulic piston and manual screw extension. It is 10 1/8" closed; 7" lift; 5 1/8" screw extension; giving an extended height of 22.25".

This jack is identical to the M10 shown on the last page.

Applicable Vehicles:

Not known

Jack Handle Type:

36" long.

Year Dates Noted:



Value:

0.99 paid on UK Ebay 7 March 2015









Lake & Elliot Millenium S929

Description

2 Ton Millennium single lift jack. Cast S929. Height closed 8.75", extended height with single lift plus screw 16.75".

This jack is the same as the M2 shown on the last page.

Applicable Vehicles:

Designed for use with Ford 2-Ton and 4-Ton trucks in 1950s.

Jack Handle Type:

Not Known

Year Dates Noted:



Value:











Lake & Elliot S945 & 945A

Description

The S945 jack is 30 cwt, single piston jack with a manual screw. Height closed 6.75", lift of 4.25" and extended height with screw 14".  The two photos courtesy of John Hawkings in Australia show the jack with the casting S945A.

Another 945A jack made known to me has 02/59 stamped on the handle lever pivot.

Applicable Vehicles:

Not known

Jack Handle Type:

Not known.

Year Dates Noted:

1959

Value:











Lake & Elliot S952

Description

The S952 jack is an 8 ton, single piston jack with a manual screw. Height closed 9.5", hydraulic lift of 5.5"; screw lift of 5" giving an overall height of 20".  Cast on one side LAKE & ELLIOT LTD 8000KG 8 TON S952 and on the other MILLEX MADE IN ENGLAND.

Applicable Vehicles:

Not known

Jack Handle Type:

Not known.

Year Dates Noted:



Value:













Lake & Elliot HY959

Description

The HY959 jack is 5/7 Ton, single piston jack with a manual screw. Height closed 8 1/2". Markings as shown in the photos.  The patent numbers would date the jack to circa 1931. Photos and information courtesy of NewMoody.

Applicable Vehicles:

Not known

Jack Handle Type:

Not known.

Year Dates Noted:



Value:









Lake & Elliot Millennium Master

Description

The Millennium Master is is a double hydraulic piston plus a manual screw extension. Height closed is 5 7/8". Piston lift is 7 5/8" and the screw extension is 4 1/8" giving a total height of 17 5/8".

Schematic from R Cadisch & Sons catalogue circa 1930 - kindly supplied by Tore Karlsson.

Applicable Vehicles:

Not known

Jack Handle Type:

As shown.

Year Dates Noted:



Value:











Lake & Elliot Millennium 10 Ton

Description

The Millennium 10 Ton is a single hydraulic piston with a large manual screw extension. Height closed is 12 1/2". Piston lift is 8" and the screw extension is 7 1/4" giving a total height of 27 3/4".

Schematic from R Cadisch & Sons catalogue circa 1930 - kindly supplied by Tore Karlsson.

Applicable Vehicles:

Not known

Jack Handle Type:

As shown

Year Dates Noted:



Value:











Lake & Elliot CV Hydro

Description

This is a 12 ton jack with a single piston and manual screw extension.  On one side it is cast MILLENNIUM CV HYDRO 12 TON 1946. On the other is cast LAKE & ELLIOT LTD BRAINTREE ENGLAND

Applicable Vehicles:

Not Known

Jack Handle Type:

Round bar 36".

Year Dates Noted:

1946

Value:

0.99 paid on UK Ebay 19 May 2014





Millennium MO Jacks











Lake & Elliot Millennium MO Jacks

The Lake & Elliot Millennium MO range of jacks consist of the MO.1 1/2, MO.3, MO.5, MO.10, MO.12 and MO.20.

Graphic extracted from Lake & Elliot 1965 catalogue, courtesy of Pinto Ribeiro.









Lake & Elliot Unknown

Description

This L&E jack is in the style of the following Millennium jacks. Unfortunately it is minus its label. One feature that stands apart is the Stud/flat headed nut that features on the front face. All the other jacks below have that stud on the side opposite the pump. Any information most welcome.

Applicable Vehicles:

Not Known

Jack Handle Type:

Metal rod 24" long

Year Dates Noted:



Value:

19.99 paid on UK Ebay 26 August 2017 - NH











Lake & Elliot Millennium MO 1 1/2

Description

1.5 ton jack. Single piston hydraulic jack with a single manual screw extension.  It measures 6.75" closed with a 4.5" hydraulic lift and a 3" screw extension. Extended height is 14.25".

Applicable Vehicles:

Not Known

Jack Handle Type:

Metal rod 24" long

Year Dates Noted:



Value:

5.00 paid on UK Ebay 6 September 2015 - no handle

0.99 paid on UK Ebay 20 November 2015 - with handle





Awaiting photo, but similar to the MO.1 1/2 above



Lake & Elliot Millennium MO 3

Description

3 ton jack. Single piston hydraulic jack with a single manual screw extension.  It measures 9.25" closed with a 6.25" hydraulic lift and a 3.5" screw extension. Extended height is 19".

Applicable Vehicles:

Not Known

Jack Handle Type:

Metal rod 30" long.

Year Dates Noted:



Value:











Lake & Elliot Millennium MO 5

Description

5 ton jack. Single piston hydraulic jack with a single manual screw extension.  It measures 8.75" closed with a 6.25" hydraulic lift and a 4.25" screw extension. Extended height is 19.25".

Photos courtesy of Robert Owen.

Applicable Vehicles:

Not Known

Jack Handle Type:

Metal rod 30" long.

Year Dates Noted:



Value:

10.00 paid privately March 2015

15.00 paid on UK Ebay 12 September 2017 - NH









Lake & Elliot Millennium MO 8

Description

8 ton jack. Single piston hydraulic jack with a single manual screw extension.  It measures 9" closed with a 6.25" hydraulic lift and a 4.5" screw extension. Extended height is 19.75". Second and third pictures courtesy of Richard Tedeschi.

The 4th photo shows the jack with a different saddle.

Applicable Vehicles:

Not Known

Jack Handle Type:

Metal rod 30" long.

Year Dates Noted:



Value:

Average price paid in 2013 = 13.37 - 7 sales

Average price paid in 2014 = 6.65 - 5 sales

0.99 paid on UK Ebay 6 June 2015

2.20 paid on UK Ebay 16 July 2017 NH









Lake & Elliot Millennium MO 10

Description

10 ton jack. Single piston hydraulic jack with a single manual screw extension.  It measures 9" closed with a 6.25" hydraulic lift and a 4.5" screw extension. Extended height is 19.75".

Applicable Vehicles:

Not Known

Jack Handle Type:

Metal rod 30" long.

Year Dates Noted:



Value:

8.00 paid on UK Ebay 14 September 2013

9.99 paid on UK Ebay 2 September 2014

7.00 paid on UK Ebay 13 December2015 - NH

2.20 paid on UK Ebay 23 June 2016 - NH





Awaiting photo, but similar to the MO.10 above



Lake & Elliot Millennium MO 12

Description

12 ton jack. Single piston hydraulic jack with a single manual screw extension.  It measures 9" closed with a 6" hydraulic lift and a 4.25" screw extension. Extended height is 19.25".

Applicable Vehicles:

Not Known

Jack Handle Type:

Metal rod 30" long.

Year Dates Noted:



Value:









Lake & Elliot Millennium MO 20

Description

20 ton jack. Single piston hydraulic jack with a single manual screw extension.  It measures 11 1/8" closed with a 7 7/16" hydraulic lift and a 2.5" screw extension. Extended height is 21 1/16".

Applicable Vehicles:

Not Known

Jack Handle Type:

Metal rod 30" long.

Year Dates Noted:



Value:
