Lake & Elliot Jacks Page 3
|
Last updated
24 September 2024
|
|
Other vintage British car jack databases:
George Radion in Australia has a database on Australian-made Jacks
Request to vendors: Please feel free to use the information from these databases in your adverts. An acknowledgement of the source would be most welcome. However, please do not twist any of the information. Where I say along the lines: 'May be for car X' please make this clear in your advert. An altered statement saying: 'It is for car X' will create false facts and misinformation. If you know for certainty a jack's heritage please contact me so that I can amend the entry. Thank you.
Page 1: Uncategorised Old Jacks, Millennium Jacks, Capstan Jacks and Midas Screw Jacks.
Page 2: Sequentially numbered screw jacks.
Page 3: Hydraulic jacks and Millennium MO series hydraulic jacks.
Page 4: Millex & Millennium M series hydraulic jacks, Trolley jacks, Tipper jacks and Scissor Jacks.
I am frequently contacted by L&E hydraulic jack owners how to lower their jack. Commonly, they find the jack in the back of their garage and the first thing they do is pump it up without weight on it to see if it still works. The answer is to push the handle fully down through a restriction. This operates a pressure release piston. At the same time push down on the central lifting ram. In normal operation the weight of the car would apply this downward pressure.
See home page for the supplier of L&E jack seals.
Hydraulic Jacks followed by Millennium MO series
|
|
Description This 4 Ton hydraulic jack has a single ram and a manual screw extension. Height 9 inches closed and 18 inches fully extended. On one side it is cast LAKE & ELLIOT LTD BRAINTREE MADE IN ENDLAND. On the other 4 TON PATENT Nos 322507 369761. Applicable Vehicles: Not known Jack Handle Type: 33 inches long with metal T. Instructions for use on brass plaque at top of handle (last 2 photos) Year Dates Noted:
Value: Average price paid in 2020 = £18.00 - 1 sale
|
|
|
Lake & Elliot A5-212 Description The jack is engraved A5-212 D 93/2 5000KG 27730.4 It is 8.5" closed. It appears to be a single ram with a manual screw extension. No other details known. Applicable Vehicles: Not known Jack Handle Type: Integrated Year Dates Noted: February 1993 (D 92/2) Value:
|
|
|
Lake & Elliot S133 Description The S133 is a 4 ton jack with a double ram and manual screw extension. It is 6.75" closed; 6.75" lift; 1.5" screw extension; giving an extended height of 15." Applicable Vehicles: Not known Jack Handle Type: 36" long. Year Dates Noted:
Value: Average price paid in 2014 = £14.16 - 3 sales Average price paid in 2016 = £5.95 - 1 sale Average price paid in 2018 = £27.99 - 1 sale Average price paid in 2020 = £8.00 - 2 sales Average price paid in 2021 = £16.00 - 1 sale
|
     |
Lake & Elliot Unstamped Hydraulic Description This jack is a double ram with a manual screw extension. It measures 7" closed and 13" fully extended plus 2.75" with the manual screw extension. It does not have a casted number so I have placed it here as it has similarities to the S133 immediately above. It is cast TON LAKE & ELLIOT ENGLAND on one side and a solitary M on the other behind the pump lever. Several numbers are punched into the top nut including 7 TON. More significantly the underside of the jack has the military arrow and the date 1979 plus 3194 No 790013 OM/13. Applicable Vehicles: Unknown military application. Jack Handle Type: 36" long. Year Dates Noted: 1979
Value: |
|
|
Lake & Elliot S142 Description The S142 is a 6 ton jack with a single ram and manual screw extension. Height closed 9 5/8"; lift 6.5"; screw extension 5 3/8"; giving an extended height of 21.5" It is cast MILLENNIUM on the lever and MADE IN ENGLAND on the body. On the other side it is cast LAKE & ELLIOT LTD 6 TON S142. May have either the round jacking pad as shown in the photos or a saddle. Applicable Vehicles: Not Known Jack Handle Type: 36" long as shown in final photo. Year Dates Noted:
Value: Average price paid in 2013 = £4.77 - 3 sales Average price paid in 2014 = £11.49 - 2 sales Average price paid in 2015 = £7.33 - 3 sales Average price paid in 2017 = £10.00 - 1 sale Average price paid in 2018 = £14.83 - 3 sales Average price paid in 2019 = £13.58 - 6 sales Average price paid in 2020 = £11.24 - 4 sales Average price paid in 2021 = £9.90 - 2 sales Average price paid in 2022 = £15.08 - 6 sales Average price paid in 2023 = £20.00 - 1 sale £19.99 paid on UK Ebay 10 September 2024 - NH £34.01 paid on UK Ebay 10 September 2024 - WH
|
|
|
Description This S142 differs slightly from the one above. The handle lever is cast P11xx instead of MILLENNIUM and it has a shouldered lifting pin instead of a ring. The other casting detail is also different. This one states S142 LAKE & ELLIOT LTD BRAINTREE 6 TON. Above the lever is 9 1/2. As above it is a 6 ton jack with a single piston and manual screw extension. Height closed 9 5/8"; lift 6.5"; screw extension 5 3/8"; giving an extended height of 21.5" Photos and details courtesy of John Hawking in Australia. Applicable Vehicles: Not Known Jack Handle Type: 36" long rectangular bar with wooden grip. Year Dates Noted:
Value: Average price paid in 2018 = £25.00 - 1 sale
|
|
|
Lake & Elliot S143 Description The S143 is a 12 ton jack with a single ram and manual screw extension. It is 12.5" closed; 7 7/8" lift; 6.5" screw extension; giving an extended height of 26 7/8". Cast with S143. Millennium C V Hydro. 12 Ton. Applicable Vehicles: Not Known Jack Handle Type: 36" long Year Dates Noted:
Value: Average price paid in 2013 = £21.11 - 1 sale
|
|
|
Description The S158 is a single ram with a manual extension. Cast S158 LAKE & ELLIOT LTD BRAINTREE 6 TON. The arm is cast MILLENNIUM. It is 8 inches high when closed. The hydraulic extension is 5 inches and the screw extension is 4.5 inches. Photos and data courtesy of Martin Richardson. Applicable Vehicles: Not known Jack Handle Type: Probably a 30 -36 inch rectangular bar. Year Dates Noted:
Value: Average price paid in 2018 = £12.00 - 1 sale Average price paid in 2019 = £5.50 - 1 sale £24.99 paid on UK Ebay 8 August 2024 - NH
|
|
|
Lake & Elliot H277 Description Cast with LAKE & ELLIOT LTD BRAINTREE on one side and H277 on the other. No other details known. Applicable Vehicles: Not known Jack Handle Type: Not known Year Dates Noted:
Value:
|
|
|
Description The H278 is a single ram with manual screw extension. Cast with LAKE & ELLIOT LTD BRAINTREE ENG on one side and PAT No. 273900 869761 H278 on the other. Applicable Vehicles: Not known Jack Handle Type: Metal bar 36" long as shown in last photo. Year Dates Noted:
Value: Average price paid in 2019 = £9.99 - 1 sale
|
|
|
Lake & Elliot H281A Description Cast with H281A LAKE & ELLIOT LTD BRAINTREE 7 TON. No other details known. Applicable Vehicles: Not known Jack Handle Type: Not known Year Dates Noted:
Value: Average price paid in 2015 = £20.00 - 1 sale Average price paid in 2016 = £10.00 - 1 sale Average price paid in 2021 = £27.00 - 1 sale
|
|
|
Description The S343A is a 6 ton jack with a single ram and manual screw extension. It is 9.25" closed; 6 1/8" lift; 4.25" screw extension; and extended height of 19 5/8". Cast on one side 6 TON HYDRO PATENT Nos 322567 359761 and on the other LAKE & ELLIOT LTD BRAINTREE ENGLAND S343A 9 1/4 INCHES. It looks like the same casting as the MILLENNIUM M6 DP. Photos courtesy of Brod Hart. Applicable Vehicles: Not Known Jack Handle Type: 36" long. Year Dates Noted:
Value:
|
|
|
Description The jack is a 2 Ton. No other details known. Applicable Vehicles: Not Known Jack Handle Type: Not Known Year Dates Noted:
Value: Average price paid in 2014 = £4.00 - 1 sale
|
    |
Description The S356 is a 4 Ton jack with a single ram and manual screw extension. It is cast LAKE & ELLIOT LTD 4 TON S356. Height closed 9.25"; lift 6.5"; 5 3/8" screw extension; and extended height of 21 1/8". Applicable Vehicles: Not Known Jack Handle Type: 36" long. Year Dates Noted:
Value: Average price paid in 2021 = £15.00 - 1 sale Average price paid in 2023 = £9.50 - 1 sale £5.00 paid on UK Ebay 18 March 2024 - WH £12.50 paid on UK Ebay 21 August 2024 - NH
|
|
|
Description The S356B is a 4 Ton jack with a single ram and manual screw extension. It is cast LAKE & ELLIOT LTD 4 TON S356 B. Height closed 9.25"; lift 6.5"; 5 3/8" screw extension; and extended height of 21 1/8". The obvious difference to the S356 above appears to be an altered moulding of the main body. The final picture shows the jack in its component parts. All photos courtesy of Ezechiel Busutti who carried out a very nice restoration. Applicable Vehicles: Not Known Jack Handle Type: 36" long. Year Dates Noted:
Value: Average price paid in 2013 = £2.99 - 2 sales Average price paid in 2014 = £13.83 - 3 sales Average price paid in 2019 = £15.00 - 1 sale Average price paid in 2020 = £2.50 - 1 sale
|
      |
Description The S385 is a 1 Ton jack with a single ram and manual screw extension. It is cast 7 INS LAKE & ELLIOT LTD BRAINTREE S385 on one side and 1 TON HYDRO PAT Nos 322507 341586 on the other. Height closed 7". Photos Courtesy of Peter Bentley. Applicable Vehicles: Not Known Jack Handle Type: 29" long with instructions (last photo). Year Dates Noted:
Value: Average price paid in 2021 = £10.50 - 1 sale
|
|
|
Lake & Elliot Midas S388 Description The S388 is a 6 Ton jack with double rams and manual screw extension. Height closed 8 1/8"; lift 8.75"; screw extension 2.5"; giving an extended height of 19 3/8". Applicable Vehicles: Not known Jack Handle Type: 36" long. Year Dates Noted: 1953 Value: Average price paid in 2013 = £1.11 - 1 sale Average price paid in 2014 = £10.00 - 1 sale Average price paid in 2017 = £8.00 - 1 sale Average price paid in 2018 = £18.00 - 1 sale Average price paid in 2022 = £10.00 - 2 sales
|
|
|
Lake & Elliot S391 Description The S391 is an 8 Ton jack with double rams and manual screw extension. It is cast S391 LAKE & ELLIOT BRAINTREE ENGLAND 10 1/4 IN on one side and MILLENNIUM HYDRO 8 TON on the other. Height closed 10.25". Photos and information courtesy of NewMoody. Applicable Vehicles: Not known Jack Handle Type: 36" long, as shown in 4th photo. I believe the rivet in the handle is designed to hit the cast stop when raising. To lower I presume the handle is rotated and the socket is then pushed down past the cast stop. Year Dates Noted:
Value: £24.99 paid on UK Ebay 23 September 2024 - WH |
|
|
Lake & Elliot S473 Description The S473 is a 4 Ton jack It has double rams with a manual screw extension. Height closed 8.75", double lift 10 3/8", screw lift 3", giving an extended height of 22 1/8". It is cast LAKE & ELLIOT LTD BRAINTREE ENGLAND S473 6 1/2 INS on one side and 4 TON HYDRO PAT Nos 322387 069761 on the other. Applicable Vehicles: Not known. Jack Handle Type: 36" long as shown in final 2 photos. Year Dates Noted:
Value: Average price paid in 2013 = £7.00 - 1 sale Average price paid in 2016 = £8.50 - 1 sale Average price paid in 2019 = £10.00 - 1 sale Average price paid in 2020 = £10.00 - 1 sale
|
|
|
Lake & Elliot S640 Description The S640 is an 8 ton jack with a single ram and manual screw extension. Height closed 10 1/8"; lift 7"; screw extension 5 1/8"; giving an extended height of 22.25" Applicable Vehicles: Not Known Jack Handle Type: 36" long. Year Dates Noted:
Value: Average price paid in 2018 = £9.99 - 1 sale
|
|
|
Description The S646 is a 1 ton jack. It is a single ram and a manual screw extension. The hydraulic raising appears to be by a rotating lug. Cast with LAKE & ELLIOT LTD BRAINTREE on one side and 1 TON S646 + patent numbers as shown in the photos. Height closed is 7"; lift 4.75"; screw extension 3 7/8"; extended height 15 5/8". Applicable Vehicles: Not Known Jack Handle Type: As shown in photos. Interesting riveted plate on handle giving operating instructions. length 30". Year Dates Noted: 1956 Value: Average price paid in 2013 = £19.19 - 1 sale Average price paid in 2014 = £17.74 - 2 sales Average price paid in 2016 = £32.99 - 1 sale Average price paid in 2020 = £19.32 - 3 sales |
|
|
Description The Millennium S723 is a 1 ton jack with double rams and manual screw extension. It is 5" closed; 6 1/8" lift; 2" screw extension; giving an extended height of 13 1/8". Last photo shows the jack in an advert at the 1951 Motor Show (credit Grace's Guide). Applicable Vehicles: Aston Martin DB2 and DB2/4. I also have the M1DL (very similar specification) listed for the DB2/4. However, I believe it is a much later jack, being in production in the 1970s, probably after the DB2/4 production ceased. Information required please. The Dunlop LJ46B also has the same casting but I do not know its provenance. Jack Handle Type: 30" long with brass plate on shaft cast with raising and lowering instructions (final two photos). Year Dates Noted: 1951 Value: Average price paid in 2014 = £161.07 - 5 sales Average price paid in 2015 = £182.90 - 7 sales Average price paid in 2016 = £107.66- 3 sales Average price paid in 2017 = £70.00 - 5 sales Average price paid in 2018 = £110.00 - 4 sales Average price paid in 2019 = £88.27 - 1 sale Average price paid in 2020 = £61.33 - 3 sales |
|
|
Lake & Elliot S794 Description The Millennium S794 is a 20 ton jack with a single ram and manual screw extension. It is 10.5" closed; 6.25" lift; 4.25" screw extension; giving an extended height of 21" This jack looks identical to the M20 shown on the final page. Applicable Vehicles: Not known Jack Handle Type: 36" long. Year Dates Noted: 1954 Value: Average price paid in 2016 = £5.00 - 1 sale
|
|
|
Lake & Elliot S829 Description The Millennium S829 is a 10 ton jack with a single ram and manual screw extension. It is 10 1/8" closed; 7" lift; 5 1/8" screw extension; giving an extended height of 22.25". This jack is identical to the M10 shown on the last page. Applicable Vehicles: Not known Jack Handle Type: 36" long. Year Dates Noted:
Value: Average price paid in 2015 = £0.99 - 1 sale
|
|
|
Description The S929 is 2 ton with a single ram and a manual screw extension. Cast S929 2 TON on one side and LAKE & ELLIOT LTD MADE IN ENGLAND on the other. The handle socket is cast MILLENNIUM. Height closed 8.75", extended height with single lift plus screw 16.75". This jack is the same as the M2 shown on the last page. Applicable Vehicles: Designed for use with Ford 2-Ton and 4-Ton trucks in 1950s. Jack Handle Type: 30 inch rectangular bar as shown in final 3 photos. Year Dates Noted:
Value: Average price paid in 2019 = £32.49 - 2 sales
|
|
|
Description The S945 jack is 30 cwt, single ram with a manual screw extension. Height closed 6.75", lift of 4.25" and extended height with screw 14". The two photos courtesy of John Hawkings in Australia show the jack with the casting S945A. Another 945A jack made known to me has 02/59 stamped on the handle lever pivot. Applicable Vehicles: Not known Jack Handle Type: 46cm bar as shown in the final photo, courtesy of Bruce Mayo. Year Dates Noted: 1959 Value: Average price paid in 2018 = £5.99 - 1 sale Average price paid in 2019 = £7.42 - 2 sales Average price paid in 2020 = £17.35 - 2 sales
|
|
|
Lake & Elliot S952 Description The S952 jack is an 8 ton, single ram with a manual screw. Height closed 9.5", hydraulic lift of 5.5"; screw lift of 5" giving an overall height of 20". Cast on one side LAKE & ELLIOT LTD 8000KG 8 TON S952 and on the other MILLEX MADE IN ENGLAND. Applicable Vehicles: Not known Jack Handle Type: Not known. Year Dates Noted:
Value:
|
|
|
Lake & Elliot HY959 Description The HY959 jack is 5/7 Ton, with a single ram and a manual screw extension. Height closed 8 1/2". Markings as shown in the photos. The patent numbers would date the jack to circa 1931. Photos and information courtesy of NewMoody. Applicable Vehicles: Not known Jack Handle Type: Not known. Year Dates Noted:
Value:
|
     |
Description The HY1102 jack is a single ram lift (SL), dual pump (DP) hydraulic jack with a single manual screw extension. Closed height is 19cm. On one side it is cast HYDRO SL DP PAT Nos 322507 341586. On the otherside is LAKE & ELLIOT LTD BRAINTREE HY1102. Unusual for this type of jack to have an additional base plate. Applicable Vehicles: Not known Jack Handle Type: Similar to others shown above with a brass plaque and instructions. Year Dates Noted:
Value: |
|
|
Lake & Elliot Millennium Master Description The Millennium Master is is a double ram plus a manual screw extension. Height closed is 5 7/8". Piston lift is 7 5/8" and the screw extension is 4 1/8" giving a total height of 17 5/8". Schematic from R Cadisch & Sons catalogue circa 1930 - kindly supplied by Tore Karlsson. Applicable Vehicles: Not known Jack Handle Type: As shown. Year Dates Noted:
Value:
|
|
|
Lake & Elliot Millennium 10 Ton Description The Millennium 10 Ton is a single ram with a manual screw extension. Height closed is 12 1/2". Piston lift is 8" and the screw extension is 7 1/4" giving a total height of 27 3/4". Schematic from R Cadisch & Sons catalogue circa 1930 - kindly supplied by Tore Karlsson. Applicable Vehicles: Not known Jack Handle Type: As shown Year Dates Noted:
Value:
|
|
|
Lake & Elliot CV Hydro Description This is a 12 ton jack with a single ram and manual screw extension. On one side it is cast MILLENNIUM CV HYDRO 12 TON 1946. On the other is cast LAKE & ELLIOT LTD BRAINTREE ENGLAND Applicable Vehicles: Not Known Jack Handle Type: Round bar 36". Year Dates Noted: 1946 Value: Average price paid in 2014 = £0.99 - 1 sale Average price paid in 2020 = £20.00 - 1 sale
|
|
|
|
|
|
Lake & Elliot Millennium MO Jacks The Lake & Elliot Millennium MO range of jacks consist of the MO.1 1/2, MO.3, MO.5, MO.10, MO.12 and MO.20.
Graphic extracted from Lake & Elliot 1965 catalogue, courtesy of Pinto Ribeiro.
|
|
|
Description This L&E jack is in the style of the following Millennium jacks. Unfortunately it is minus its label. One feature that stands apart is the Stud/flat headed nut that features on the front face. All the other jacks below have that stud on the side opposite the pump. Any information most welcome. Applicable Vehicles: Not Known Jack Handle Type: Metal rod 24" long Year Dates Noted:
Value: Average price paid in 2017 = £19.99 - 1 sale
|
|
|
Lake & Elliot Millennium MO 1 1/2 Description 1.5 ton jack. Single ram with a manual screw extension. It measures 6.75" closed with a 4.5" hydraulic lift and a 3" screw extension. Extended height is 14.25". Applicable Vehicles: Not Known Jack Handle Type: Metal rod 24" long Year Dates Noted:
Value: Average price paid in 2015 = £2.99 - 2 sales Average price paid in 2018 = £14.50 - 2 sales Average price paid in 2019 = £3.50 - 1 sale Average price paid in 2021 = £10.00 - 1 sale
|
|
|
Description The MO 2/1 is a 2 ton jack. Single ram with a manual screw extension. Other details as shown in the photos. Applicable Vehicles: Not Known Jack Handle Type: Metal tube 30" long. Year Dates Noted:
Value: Average price paid in 2020 = £5.00 - 1 sale
|
|
Awaiting photo, but similar to the MO.1 1/2 above |
Lake & Elliot Millennium MO 3 Description 3 ton jack. Single ram with a manual screw extension. It measures 9.25" closed with a 6.25" hydraulic lift and a 3.5" screw extension. Extended height is 19". Applicable Vehicles: Not Known Jack Handle Type: Metal rod 30" long. Year Dates Noted:
Value: Average price paid in 2023 = £6.00 - 1 sale
|
|
|
Lake & Elliot Millennium MO 5 Description 5 ton jack. Single ram with a single manual screw extension. It measures 8.75" closed with a 6.25" hydraulic lift and a 4.25" screw extension. Extended height is 19.25". Photos courtesy of Robert Owen. Applicable Vehicles: Not Known Jack Handle Type: Metal rod 30" long. Year Dates Noted:
Value: Average price paid in 2015 = £10.00 - 1 sale Average price paid in 2017 = £15.00 - 1 sale Average price paid in 2020 = £9.00 - 2 sales |
|
|
Description 8 ton jack. Single ram with a single manual screw extension. It measures 9" closed with a 6.25" hydraulic lift and a 4.5" screw extension. Extended height is 19.75". Second and third pictures courtesy of Richard Tedeschi. The 4th photo shows the jack with a different saddle. Applicable Vehicles: Not Known Jack Handle Type: Metal rod 30" long. Year Dates Noted:
Value: Average price paid in 2013 = £13.37 - 7 sales Average price paid in 2014 = £6.65 - 5 sales Average price paid in 2015 = £0.99 - 1 sale Average price paid in 2017 = £2.20 - 1 sale Average price paid in 2018 = £11.00 - 1 sale Average price paid in 2020 = £12.00 - 1 sale Average price paid in 2021 = £4.95 - 1 sale Average price paid in 2022 = £9.99 - 1 sale Average price paid in 2023 = £9.99 - 1 sale
|
|
|
Lake & Elliot Millennium MO 10 Description 10 ton jack. Single ram with a single manual screw extension. It measures 9" closed with a 6.25" hydraulic lift and a 4.5" screw extension. Extended height is 19.75". Applicable Vehicles: Not Known Jack Handle Type: Metal rod 30" long. Year Dates Noted:
Value: Average price paid in 2013 = £8.00 - 1 sale Average price paid in 2014 = £9.99 - 1 sale Average price paid in 2015 = £7.00 - 1 sale Average price paid in 2016 = £2.20 - 1 sale Average price paid in 2021 = £21.00 - 1 sale Average price paid in 2022 = £25.00 - 1 sale
|
|
Awaiting photo, but similar to the MO.10 above |
Lake & Elliot Millennium MO 12 Description 12 ton jack. Single ram with a single manual screw extension. It measures 9" closed with a 6" hydraulic lift and a 4.25" screw extension. Extended height is 19.25". Applicable Vehicles: Not Known Jack Handle Type: Metal rod 30" long. Year Dates Noted:
Value:
|
|
|
Lake & Elliot Millennium MO 20 Description 20 ton jack. Single ram with a single manual screw extension. It measures 11 1/8" closed with a 7 7/16" hydraulic lift and a 2.5" screw extension. Extended height is 21 1/16". Applicable Vehicles: Not Known Jack Handle Type: Metal rod 30" long. Year Dates Noted:
Value:
|
|
|
Lake & Elliot Millennium MO (Unknown) Description The jack has 2 hydraulic rams plus a manual screw extension. It is 7.25" closed and 16" fully extended. The only other details as shown in the pictures. The adhesive label is missing. I am wondering if this may be the MO3 or MO12 for which I have no pictures. Information required. Applicable Vehicles: Not Known Jack Handle Type: Not known Year Dates Noted:
Value: Average price paid in 2016 = £5.95 - 1 sale Average price paid in 2019 = £3.30 - 2 sales Average price paid in 2022 = £5.00 - 1 sale
|
